The product is a new environmental friendly thermal insulation material. Manufactured with a patented closed-cell foam structure sandwiched by highly reflective foil surfaces, it is the fibre-free, non-allergenic alternative to conventional bulk insulation. Designed for warehouses and commercial or industrial sheds where the insulation acts as the wall or ceiling lining. 3-in-1 insulation, vapour barrier and radiant barrier.
We can also do reflective anti-glare insulation, it can protect the eyes of construction workers from being hurt by strong sunlight reflection, make the construction process safer.
Reflective foil XPE foam is your solution for shed insulation, achieving comfortable indoor temperatures that are significantly cooler in summer and warmer in winter.
| Model Number |
XPE-AL-206 |
| Product Name |
Aluminum Foil xpe foam Insulation |
| Type | Aluminum silicate products |
| Material | Aluminum Foil,XPE foam |
| Aluminum foil thickness |
7-12 microns |
| Material structure | AL + XPE + AL |
| Thickness | 3 - 15mm (Can be customized) |
| XPE colors | Blue, Green, Red (Can be customized) |
| Square gram weight | 120 - 800g / m2 |
| Packing size | 1.2*40m / 1.2*30m / 1.35*22.25m (Can be customized) |
| Reflectivity | 97% |
| Flame retardant grade | Less than 5 (AS1530.2) |
| Thermal conductivity | 0.039w / m2 * k |
| Withstand temperature | -40 ℃ ~ 80 ℃ |
- No harmful substances, comply with ROHS international environmental certification requirements, so it will not produce any pollutants harmful to human body during installation and application;
- High-quality insulation and energy-saving materials are the nemesis of heat insulation and dew condensation. The thermal conductivity is low and stable, and it has the effect of isolating any heat medium;
- Waterproof, flame retardant, thermal insulation, shock absorption, sound absorption, noise reduction and other functions;
- It has the characteristics of light weight, easy processing and easy installation;
- Heat resistance, low temperature resistance, chemical resistance, aging resistance and other characteristics.
